Wireless Camera Detector Full Band Video Scanner Image Display Anti-Spy Device Wireless Lens Hunter Spy Camera Detect

This new mini video scanner receives and display video signal of 1.2 GHz - 2.4 GHz - 5.8 GHz three frequency bands wireless camera. Its effective distance is up to 200 feet (depending on output power of source transmitter).




Image Display:

When detects wireless video signal, the image will display on screen and the frequency of the image will display on screen and the frequency of the image will appear in the left bottom side of screen. The duration of image display on screen is depended on the video signal strength, the stronger the longer.

This device keeps scanning, the image will fade away when scan to other frequency and the screen will shut down to save power. When detects next video signal, the screen will light up again to display the image.

Lock Image:
When detects significant image, press and hold the (+) button in left side over 1.5 seconds to lock the image. When hear beep once, the image is locked. The scan will stop and the blue and screen LEDs will still. The frequency on screen will be fixed and blink in black and white.


Video/Audio Output:
The jack in right upper side is shared by earphone and AV output .Plug in the AV output cable and connect it with DVR to record the scanned image and audio.

Fine Tune Image

After image locked,press the buttons (+) (-) in left side to tune the image at its best resolution.

Press the ( + ) once,beep once and you will find the frequency in the left bottom side of screen will be increased.

Press the ( - ) once,beep once and you will find the frequency in the left bottom side of screen will be decreased.

Audio Demodulation:

This is unique technology in its kind.Plug the earphone into the jack in right upper side to hear the audio of image.If you can not hear the audio,press and hold the (-) button in left side over 1.5 seconds to shift the audio frequency.

Warning Mode Setting

This device has three kinds of warning modes,1.Beep and vibration. 2.Vibration 3.Beep, factory default setting is "Beep and vibration".To change the warning mode,switch off this device.First press the (-) button in left side,and use another hand to switch on,this device will enter "Warning mode setting".

Press the (-) button in left side once,the warning mode will shift from 1.Beep and vibration to 2.Vibration to 3.Beep cyclic.After set the preferred warning mode,press both (+) (-) buttons to save your setting.

Features:

* Scan 1.2G - 2.4G - 5.8G three frequency bands cyclic within 18 seconds for one cycle
* 2.5" LCD Monitor, Color and B/W cameras are compatible
* Indicate frequency of scanned image
* Three LED indicates the scanning status of 3 frequency bands
individually
* Video protocol auto-switching for NTSC, PAL and SECAM
* Lock function can latch or release the image.
* "Fine Tuning" switches for mending screen image
* 3.5mmVideo/Audio output jack for recording the scanned video
and audio
* AAA / UM-4 dry battery or rechargeable battery both available
* Earphone hear the voice if there is audio signal with the wireless camera signal
* Support external power bank to extend the working time



Package contents:

1.Video scanner 2.Detachable SMA antenna*2
3.AV output cable*1 4.Swithching power adaptor*1
5.Earphone*1 6.Rechargeable batteries*4(optional)



Specifications:
